Simatec Simatool Bearing Instillation and Removal Tool Kit, MK 10-30

Simatec Simatool Bearing Instillation and Removal Tool Kit, MK 10-30

Attributes:

• Part Number: 310.1410
• Ships directly from the Simatec USA warehoutilize so you can be confident that you’re getting the newest model!
• Swiss Made
• Can be utilized for mounting and dismounting of most bearings with bore diameters from 10 – 30 mm.
• Can be utilized to mount bearings, bushings, seals, tension rollers, and other similar parts.
• Incorporates a three-armed extractor for removing deep groove ball bearings from shafts and housings
• The right combination of impact ring and sleeve ensures that the mounting forces never go through the rolling elements of a bearing, which minimizes bearing damage due to incorrect installation.
• The impact rings are made of high-strength modified resin. The impact sleeves are made of anodized aluminium, which is robust, stable and very light
• A complete set of different-sized puller arms and spindles simplifies the dismounting process of deep groove ball bearings.
• The hooks were specially advanceed to be mounted in the raceway of the bearing. This offers an optimal hold and allows for greater dismounting power.
• The flexible locking ring creates the assembly of the puller arms with the spindle easy.
• Number of impact rings: 21 (12 size A and 9 size B)
• Number of impact sleeves: 2 (size A and B)
• Puller arms A1-A5: 5 sets with 3 puller arms each
• Inner diameter of the impact rings: 10–30 mm
• Outer diameter of the impact rings: 26–72 mm
• Inner diameter of the impact sleeves: 18 und 37 mm
• Blowsupport-proof hammer: FT 33-H, weight 1,0 kg
• Substantiate rings (diameter): 10, 12, 15, 17, 20, 22, 25, 28 und 30 mm
• Spindle key width: 19 mm und 24 mm
• Sliding hammer weight / total sliding hammer weight (incl. rod): 1‘056 g / 1,716g
• Carrying case measurements (L x W x H): 440 x 348 x 97,2 mm
• Weight of the kit: 7,032 g

If you need a fast, precise way to perform bearing or seal maintenance you’re goign to want to get your hands on the Simatec Simatool MK 10-30 Bearing Instillation and Removal Tool Kit. It easily mounts bearings with a diameter of 10–30 mm, and removes deep groove ball bearings from correplying shafts and housings. The tool set includes a multipurpose mounting tool that is great for mounting bearings, bushings, seals, tension rollers, and other similar parts. The set also includes a three-armed extractor for removing deep groove ball bearings from shafts and housings. A combination of this extractor with the sliding hammer and back rings enables the simple dismounting of deep groove ball bearings from housings.
