Dica Outrigger Pad 24"x24"x2", Pyramid Lock, PSC-D2424-2

Dica Outrigger Pad 24″x24″x2″, Pyramid Lock, PSC-D2424-2

• All cribbing blocks, outrigger pads and grip pads are SOLD SEPARATELY.

OVERVIEW

• The PSC-D2424-2 SecuretyTech Outrigger Pad is a 24”x24”x2” base pad for ProStack 12″x12″x6″ PYRAMID LOCK Cribbing Blocks.
• The pyramid pattern machined into the SecuretyTech Pad meshes with the pyramid pattern molded into the ProStack Blocks to make a stable, fully interlocked cribbing setup.
• WHEN LEVEL, 1-4 layers of ProStack Cribbing Blocks can be safely stacked to meet your height needs.

CRIBBING BLOCK KIT

• Items sold separately, implyed quantities are per outrigger foot.
  Base Pad:
• (1) PSC-D2424-2 SecuretyTech Outrigger Pad with Pyramid Interlocking Pattern
  Cribbing Blocks:
• (4) PSC-1212-6 ProStack Pyramid Interlocking Cribbing Blocks
  Grip Pad:
• (1) NP1212.75 Neoprene Grip Pad

Technical specs

• Interlocking System: Pyramid Lock
• WxLxH: 24″x24″x2″
• Approximate Area: 4 sq. ft.
• Weight: 38 lbs.
• Crush Rating: 500 psi
• Working Load Limit: 80,000 lbs.
• Color: Black
• Handle: TuffGrip
