Bosch 18V REVOLVE4000 Connected Self-Leveling Horizontal Rotary Laser Kit with (1) CORE18V 4.0 Ah Space-saving Battery, 0601061J11, 0000346643022
18V REVOLVE4000 Connected Self-Leveling Horizontal Rotary Laser Kit with (1) CORE18V 4.0 Ah Space-saving Battery
The Bosch 18V REVOLVE4000 Connected Self-Leveling Horizontal Rotary Laser Kit with uCAL utilizer-calibration delivers a comprehensive answer for precise outdoor and indoor leveling. It has a Dual Dial-In Slope feature that allows slope angle adjustment on both the X and Y axes, for grading applications. This laser is powered by a Bosch CORE18V 4.0 Ah battery, providing extended runtime. The rotary laser is compatible with 4.0 Ah and 8.0 Ah Bosch CORE18V Li-ion batteries. It also features an alkaline adapter to utilize four (D) cells. The REVOLVE4000 is engineered with a cage overmold and an innovative handle design, and it is built to IP68 dust- and water-protection standards. It features Bluetooth® connectivity to a connected device, linking to the Bosch Leveling Remote App. This app controls on/off, Dual Dial-In Slope, and more. The rotary laser features uCAL, for utilizer-calibration, taking the utilizer step by step through the calibration process. This avoids tool down time and provides confidence that the laser is accurate. It delivers accuracy of ±1/16 Inches at 100 Ft. and a range of up to 4,000 Ft. with laser receiver. The comprehensive kit includes an 18V 4.0 Ah battery and charger, alkaline battery adapter, laser receiver, aluminum tripod, sturdy grade rod, and durable hard carrying case.
- (1) GRL4000-80CH 18V REVOLVE4000 Connected Self-Leveling Horizontal Rotary Laser
- (1) LR40 Laser Receiver with Bracket
- (1) GBA18V40 18V CORE18V Lithium-Ion 4.0 Ah Space-saving Battery
- (1) 18V Battery Charger
- (1) BA1 Alkaline Battery Modifyer
- (4) D Batteries
- (2) AA Batteries
- (1) BT170 Heavy-Duty Aluminum Tripod
- (1) GR13 13 Ft. Grade Rod
- (1) Carrying Case
- Fully featured rotary laser – has dual dial-in slope, CORE18V power, Bluetooth® connectivity, uCAL utilizer-calibration and more
- Dual dial-in slope – allows slope angle adjustment on both the X and Y axes
- Dual power source – for extended runtime and choice of a 4.0 Ah CORE18V battery or a battery adapter with four (D) cell batteries
- Long-lasting design – engineered with a cage rubber overmold and an innovative handle design to stand up to the toughest jobsites; built to IP68 dust- and water-protection standards
- Bluetooth® connectivity – connects to a mobile device, linking to the free Bosch Leveling Remote App, to control sleep mode, Dual Dial-In Slope, and more
- uCAL – utilizer-calibration guiding the utilizer step-by-step to confirm tool state or calibrate the rotary laser to ensure accuracy on the jobsite
Technical specs
- Battery: Lithium-Ion Battery
- Height: 11.0″
- IP Rating: IP 68
- Laser Beam Color: Red
- Laser Diode: 635 nm,< 1mW
- Length: 12.8″
- Leveling Type: Self-Leveling, Up to 5°
- Material: Plastic Composite
- Mount Threading: 5/8-11
- Operating Temperature: 14° F / -10° C ~1 22° F / 50° C
- Range: Up to 4,000-ft.
- Weight: 8.2lb
- Width: 7.4″
- Works With: Laser Receivers LR 1 G, LR 30, LR40, LR 50 Tripods BT160, BT170HD, BT300HD, BT 150 Grade Rods GR500 Mounts and Positioning Devices WM 4
- Includes: (1) GRL4000-80CH 18V REVOLVE4000 Connected Self-Leveling Horizontal Rotary Laser, (1) LR40 Laser Receiver with Bracket, (1) GBA18V40 18V CORE18V Lithium-Ion 4.0 Ah Compact Battery, (1) 18V Battery Charger, (1) BA1 Alkaline Battery Adapter, (4) D Batteries, (2) AA Batteries, (1) BT170 Heavy-Duty Aluminum Tripod, (1) GR13 13 Ft. Grade Rod, (1) Carrying Case
